Industrial CLB Series CO2 Laser Marker for Organic Material & Coated Surface

Details

CO2 laser marking system is the most accepted technology due to its versatility, minimal maintenance and nil requirements of consumables.

Black Pearl CLB Series CO2 Laser Marking Machine performs Precise & Consistent Marking in very short cycles.

Powerful and versatile CLB Series CO2 laser Markers / Engravers use a 10600nm wavelength in the infrared range, which provides a precise and permanent marking on a wide range of materials such as –

Natural materials (wood, leather, paper, fruits & vegetables)

Transparent material (glass, transparent plastics) and Coated materials (painted surfaces, anodized aluminium).

High Performance software application that extends a smooth & fully automatic production flow.

Black Pearl introduce range of systems in CLB Series considering industrial variable application -

  1. Industrial Table enclosed system for Manual Marking
  2. Fly Marking System for online marking on product surface.

Unique Feature –

  • Patented Metal Tube design technology to deliver high power during life cycle
  • High power 1.06µm laser beam for Precise marking
  • Over 50,000 hours of reliable, maintenance-free performance
  • High Speed QR code / 2D Bar Code marking
  • Compatibility with all PLCs brands, ensure quick and cost-effective integration
  • Protection against Dust & Machine safety (Shutter, alarms & controls)

Benefits –

  • Black Pearl CLB series can mark on range of Organic & Coated surfaces with no contact
  • Robust design and high-quality optical components guarantee high strength and low maintenance
  • Low use of consumables gives low recurring cost
  • Permanent & Consistent Marking that reduces traceability issue
  • High Precision & High Speed marking increase productivity

Co2 Laser Marking Applications


Technical Specification
Model Available CLB10/CLB30/CLB50
Laser Power 10W / 30W / 50W
Technology Metal Tube Design
Wavelength 1.06μm
Beam Quality < 2 (M2)
Marking Area 100 * 100 mm /150 * 150 mm /200*200mm Optional
Marking Depth 0.01 - 0.1 mm Depend on surface material
Max marking speed 7000 mm / second or 300 Character /sec.
Character Details Height - 0.2mm
Repetition Accuracy ± 0.003 mm
Cooling Mode Air cooling
Operating Temperature 15 °C - 45 °C
Life of Laser Module > 50000Hrs
Power Requirement 220V / single phase / 50Hz / < 600W
Design Software JCZ EZCAD 2.14 PROFESSIONAL FIBER LASER MARKING SOFTWARE
Support File & Format PLT, DXF, BMP, JPG, JPEG ,CAD, CDR, DWG
Support OS WINDOWS XP, 7 , 8 ,10
Communication Serial Communication RS232 , USB(X3)
Optional Fume Extraction , Rotary Chuck , Class I enclosure, Rotary Indexing, Conveyor attachment , On the Fly marking
CERTIFICATE ISO, CE, FDA

Models Available
