LED lights are one of the latest inventions of scientists for reducing the negative effects of conventional bulbs to the environment. These light bulbs use less electrical energy, which help you to save allot of your electricity bill amount.
It is a well-known fact that LED bulbs produce less heat, even if they are used for a long time. It has clearer light output than the older bulbs.
Black Pearl Solution proudly introduce as a business partner of Eetamax.
| Technical Parameters | ||
|---|---|---|
| Mechanical Specification | ||
| 1 | Fixture Housing | PDC Aluminium Alloy Housing (Heatsink) with powder coated with Separate driver box |
| 2 | Diffuser Closure | Toughened Glass |
| 3 | IP & IK | IP66 & IK08 |
| Luminaire Specification | ||
| 1 | Available Variants | 30W / 40W / 50W / 60W / 80W / 100W / 120W / 140W / 150W / 160W / 180W / 200W / 300W |
| 2 | System Efficacy ( Lm/W ) | >150 lm/W |
| 3 | L70 Life | >70,000 Br.hrs |
| 4 | Operating Temperature | From -20° to +50° C |
| LED Driver Specification | ||
| 1 | Type of Driver | Constant Current |
| 2 | Input Voltage Range | 180 VAC ~ 300 VAC |
| 3 | Power factor | > 0.97 |
| 4 | Total Harmonic Distortion | < 10 % |
| 5 | Surge Protection | 4 kV + 10 kV External SPD |
| 6 | Protection | Surge Protection, Output Short Circuit, Overload Protection, Over Voltage Protection, Thermal Protection, Mis- Wiring, 440 VAC protection |
| LED Lamp | ||
| 1 | Light Source | SMD LED & COB LED |
| 2 | CRI | >70 & >80 |
| 3 | Certification / Report | LM80, Photo Biologically safe |
| 4 | Beam Angle | 30°/60°/ 90°/120° |
| Technical Parameters | ||
|---|---|---|
| Mechanical Specification | ||
| 1 | Fixture Housing | Pressure Die Cast Aluminium with Side Contour, closed appearance, Highly weather resistance & Powder-coated. Toughened Glass Safety Cover is also provided. |
| 2 | Diffuser Closure | Toughened Glass (For Multi LED) |
| 3 | IP & IK | IP65 |
| Luminaire Specification | ||
| 1 | Available Variants | 30W / 40W / 50W / 60W / 72W / 80W / 90W / 100W / 120W / 150W / 180W / 200W |
| 2 | System Efficacy ( Lm/W ) | >120 lm/W |
| 3 | L70 Life | >50,000 Br.hrs |
| 4 | Operating Temperature | From -20° to +60° C |
| LED Driver Specification | ||
| 1 | Type of Driver | Constant Current |
| 2 | Input Voltage Range | 150 VAC ~ 265 VAC |
| 3 | Power factor | > 0.98 |
| 4 | Total Harmonic Distortion | < 10 % |
| 5 | Surge Protection | 3.75 kV |
| 6 | Protection | Surge Protection, Output Short Circuit, Overload Protection, Over Voltage Protection |
| LED Lamp | ||
| 1 | Light Source | SMD LED & COB LED |
| 2 | CRI | >70 & >80 |
| 3 | Certification / Report | LM80, Photo Biologically safe |
| 4 | Beam Angle | 90°/120° |
| Technical Parameters | ||
|---|---|---|
| Mechanical Specification | ||
| 1 | Fixture Housing | LM6 Aluminium Alloy PDC for optimum thermal management with Eye bolt & Cradle arrangement. |
| 2 | Diffuser Closure | Borosilicate Glass Lens |
| 3 | IP & IK | IP66 |
| 4 | Certification | CIMFR & PESO |
| 5 | Zones | Zone 1,2 & Zone 21,22 |
| 6 | Gas Group | IIA, IIB & IIC |
| Luminaire Specification | ||
| 1 | Available Variants | 30W / 40W / 60W / 80W / 100W / 150W / 200W |
| 2 | System Efficacy ( Lm/W ) | >120 lm/W |
| 3 | L70 Life | >60,000 Br.hrs |
| 4 | Temperature Class | T6 (Best temp. Class of < 85°C) |
| 5 | Operating Temperature | From -20° to +50° C |
| LED Driver Specification | ||
| 1 | Type of Driver | Constant Current |
| 2 | Input Voltage Range | 180 VAC ~ 300 VAC | 100 VAC ~ 305 VAC |
| 3 | Power factor | > 0.97 |
| 4 | Total Harmonic Distortion | < 10 % |
| 5 | Surge Protection | 4.0 kV / 6.0KV |
| 6 | Protection | Surge Protection, Output Short Circuit, Overload Protection, Over Voltage Protection, Thermal Protection |
| LED Lamp | ||
| 1 | Light Source | COB |
| 2 | CRI | > 80 |
| 3 | Certification / Report | LM80, Photo Biologically safe |
